By Whirlwind

Whirlwind PC USB Computer Audio USB Interface

Part #:
PCUSB
Model #:
PC USB
MSRP: $262.99
$262.00
Availability: Usually arrives in 5-9 business days. Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.
Adding to cart… The item has been added
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL
The Whirlwind PC USB computer audio USB interface converts digital USB audio into high-quality analog stereo balanced output for seamless connection to PA systems, mixers, and sound equipment. It supports multiple sample rates and includes a USB hookup cable.

Description

Williams AV BKT 024 Wall or Ceiling IR Mounting Bracket

The PC USB computer audio USB interface is a professional-grade solution for converting digital USB audio signals into high-quality analog stereo balanced output. It is designed for easy integration with PA systems, mixing consoles, and other professional audio equipment.

This interface supports sample rates of 32 kHz, 44.1 kHz, and 48 kHz, ensuring flexible compatibility across a wide range of audio sources and applications. With a maximum output of -3.4 dBV balanced at 0 dBFS input and a -20 dB input pad attenuation, it delivers clean and controlled audio performance in demanding environments.

Compact and reliable, the PC USB interface simplifies computer audio integration into professional sound systems. A USB hookup cable is included for quick and convenient setup, making it an ideal tool for live sound, installations, and broadcast applications.

Features

  • USB 2.0 compliant with no device driver required
  • Operating power supplied from USB port in the host device
  • Sample rates of 32kHz, 44.1kHz and 48kHz are supported at 16 bits
  • USB hookup cable included
  • STEREO / MONI switch to combine stereo sources into a mono signal
  • 20dB PAD switch to reduce the analog output level into sensitive microphone inputs
  • GROUND LIFT switch disconnects the outputs from the circuit ground to help eliminate hum and buzz

Specifications

Max Output -3.4dBV balanced with 0 dBfs input
Supported Sample Rates 32 kHz, 44.1 kHz, 48 kHz
Input Pad Attenuation -20dB
